Electrical Characteristics specification.

Power Inductor

Power Inductor

Power Inductor

Power Inductor

CDEPI115ME

13.3

27.0

2.77(2.31)

0.62

±25%

CDEPI115MENP-R62PC

16.3

42.0

1.72(1.43)

0.27

±25%

CDEPI115MENP-R27PC

8.4

16.5

6.73(5.61)

1.6

±25%

CDEPI115MENP-1R6PC

10.5

22.0

4.28(3.57)

1.0

±25%

CDEPI115MENP-1R0PC

5.8

12.0

14.3(11.9)

3.3

±25%

CDEPI115MENP-3R3PC

6.9

14.5

9.85(8.21)

2.4

±25%

CDEPI115MENP-2R4PC

5.4

10.0

16.3(13.6)

4.3

±25%

CDEPI115MENP-4R3PC

9.0

Saturation Current

(A)

※1

at 20

℃

4.7

22.6(18.8)

5.6

±25%

CDEPI115MENP-5R6PC

Temperature

Rise Current

(A)

※2

D.C.R. (m

Ω)

Max. (Typ.)

at 20

℃

Inductance

( H)

100KHz/1V

Sumida P/N

※1、Saturation Current: This indicates the value of DC current when the inductance decreases to 80% of

its nominal value.

※2、Temperature Rise Current: The actual current when temperature of coil becomes △T=40℃.(Ta=20℃)
