1 / 5 page

l FEATURE

特性

l DIMENSIONS(UNIT:mm)

l COLOR CODE FOR DISCRETE RESISTANCE

COLOR

1ST .FIGURE

2ND. FIGURE

MULTIPLIER

TOLERANCE(%)

Black

0

1

±20%

Brown

1

10

Red

2

100

Orange

3

1000

Yellow

4

—

Green

5

—

Blue

6

—

Purple

7

—

Gray

8

—

White

9

—

gold

—

0.1

±5%

silver

—

0.01

±10%

NOTE : EC MEANS EPOXY COATED AND TAPING WITH REEL(EC:色码电感)

TYPE

A

B

C

EC36

11.0MAX

0.65±0.05

4.0 MAX

EC24

8.0 MAX

0.55±0.05

3.0 MAX

EC22

4.0 MAX

0.50±0.05

2.8 MAX

ECXX SERIES

CONFORMAL COATED INDUCTORS

MECHANICALS

Productwell Precision Elect.Co.,Ltd

Kai Ping Productwell Precision Elect.Co.,Ltd

Tel:0750-2323113 Fax:0750-2312333

http:// www.productwell.com

1

1. Conformal coated inductors .

2. Special magnetic core structure contributes to

high Q and Self-Resonant Frequencies .

3. Epoxy coated for better reliability.

4. Wide inductance range.

5. Ideal for auto insertion

1. 色碼電感結構堅固, 成本低廉, 適合自

動化生產.

2. 特殊鐵芯材質，高 Q 值及自共振頻率.

3. 外層用環氧樹脂處理, 可靠度高.

4. 電感範圍大

5. 可自動插件

TOLERANCE(%)

MULTIPLIER

1ND FIGURE

1ST FIGURE

There is no tolerance marked for

values below 0.1uH

電感值在 0.1uH 以下時,不標示容

許公差
