3

Electronic Solutions Division

Interconnect Solutions

http://www.3M.com/interconnects/

3M is a trademark of 3M Company.

For technical, sales or ordering information call

800-225-5373

.050” Boardmount Compliant Pin Vertical Receptacle - Shielded

102 Series

TS-0961-C

Sheet 2 of 3

Ordering Information

102XX - R2XX XX

Inch

[mm]

Tolerance Unless Noted

.0

.00 .000

Inch ±.1 ±.01 ±.005

[ ] Dimensions for

Reference Only

Wiping Area Plating

S = 30 μ” [0.76 μm] Min. Gold

FB = 8 μ” [0.2 μm] Min. Gold

with Lubricant

15°

.19

[ 4.8 ]

.05

[ 1.3 ]

Position 1

Position 2

.05

[ 1.3 ]

E

D

.050 [ 1.27 ]

A

C

B

.23

[ 5.8 ]

.21

[ 5.2 ]

(2X) Lockstand Thread

see ordering information

below

.18

[ 4.6 ]

Last Position

.050

[ 1.27 ]

.25

[ 6.3 ]

.36

[ 9.1 ]

Position

Note:

1. Use mounting screws to PCB when using Junction Shells.

Contact Quantity

(See Table)

.075

[ 1.91 ]

.075

[ 1.91 ]

.075

[ 1.91 ]

.016

[ 0.40 ]

.160

[ 4.00 ]

.28

[ 7.2 ]

Contact

Quantity

Dimension

A

B

C

D

E

14

.300 [ 7.62 ]

.93 [ 23.6 ]

1.16 [ 29.5 ]

.50 [ 12.6 ]

.77 [ 19.5 ]

20

.450 [ 11.43 ]

1.08 [ 27.45 ]

1.31 [ 33.4 ]

.65 [ 16.4 ]

.92 [ 23.4 ]

26

.600 [ 15.24 ]

1.23 [ 31.3 ]

1.46 [ 37.2 ]

.80 [ 20.2 ]

1.07 [ 27.2 ]

36

.850 [ 21.59 ]

1.48 [ 37.6 ]

1.71 [ 43.5 ]

1.05 [ 26.6 ]

1.32 [ 33.5 ]

40

.950 [ 24.13 ]

1.58 [ 40.2 ]

1.81 [ 46.1 ]

1.15 [ 29.1 ]

1.42 [ 36.1 ]

50

1.200 [ 30.48 ]

1.83 [ 46.5 ]

2.06 [ 52.4 ]

1.40 [ 35.5 ]

1.67 [ 42.4 ]

68

1.650 [ 41.91 ]

2.28 [ 57.9 ]

2.51 [ 63.8 ]

1.85 [ 46.9 ]

2.12 [ 53.8 ]

80

1.950 [ 49.53 ]

2.58 [ 65.6 ]

2.81 [ 71.5 ]

2.15 [ 54.5 ]

2.42 [ 61.5 ]

Lockstand Thread

0 = M2.6 (Special order)

1 = M2.5 (Standard)

Note:

2. Assembly tools: 3M™ Stopper

Press Block 10992-XX.

PCB Press Fit Hole Compatibility

C = Cu/pre-flux PCB holes. Contacts with gold

flash tail plating (App. E1 & C1 apply)

T = Solder plated PCB holes. Contacts with gold

flash tail plating (App. E1 & C1 apply)
