B227

Note1: Tape and reel packaging(500 pieces/reel). Order by number of reels.

Note2: The 40 contacts connector is merchandized in combination with the SMT product.

Note3: Embossed packaging products have the reel wrapped in polyethylene and include a desiccant.

Unit: mm

Part Number

CL Numer

Part Number

CL Numer

Number of contacts

A

B

C

RoHS

Tin plated

Gold plated

DF11CZ- 4DP-2V(27)

DF11CZ- 6DP-2V(27)

DF11CZ- 8DP-2V(27)

DF11CZ-10DP-2V(27)

DF11CZ-12DP-2V(27)

DF11CZ-14DP-2V(27)

DF11CZ-16DP-2V(27)

DF11CZ-18DP-2V(27)

DF11CZ-20DP-2V(27)

DF11CZ-22DP-2V(27)

DF11CZ-24DP-2V(27)

DF11CZ-26DP-2V(27)

DF11CZ-28DP-2V(27)

DF11CZ-30DP-2V(27)

DF11CZ-32DP-2V(27)

DF11CZ-40DP-2V(27)

0543-2047-4-27

0543-2048-7-27

0543-2049-0-27

0543-2050-9-27

0543-2051-1-27

0543-2052-4-27

0543-2053-7-27

0543-2054-0-27

0543-2055-2-27

0543-2056-5-27

0543-2057-8-27

0543-2058-0-27

0543-2059-3-27

0543-2060-2-27

0543-2061-5-27

0543-2062-8-27

DF11C- 4DP-2V(57)

DF11C- 6DP-2V(57)

DF11C- 8DP-2V(57)

DF11C-10DP-2V(57)

DF11C-12DP-2V(57)

DF11C-14DP-2V(57)

DF11C-16DP-2V(57)

DF11C-18DP-2V(57)

DF11C-20DP-2V(57)

DF11C-22DP-2V(57)

DF11C-24DP-2V(57)

DF11C-26DP-2V(57)

DF11C-28DP-2V(57)

DF11C-30DP-2V(57)

DF11C-32DP-2V(57)

DF11C-40DP-2V(57)

0543-0682-1-57

0543-0683-4-57

0543-0684-7-57

0543-0685-0-57

0543-0686-2-57

0543-0687-5-57

0543-0688-8-57

0543-0689-0-57

0543-0690-0-57

0543-0691-2-57

0543-0692-5-57

0543-0693-8-57

0543-0694-0-57

0543-0695-3-57

0543-0696-6-57

0543-0697-9-57

4

6

8

10

12

14

16

18

20

22

24

26

28

30

32

40

2.0

4.0

6.0

8.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

38.0

8.5

10.5

12.5

14.5

16.5

18.5

20.5

22.5

24.5

26.5

28.5

30.5

32.5

34.5

36.5

44.5

8.7

10.7

12.7

14.7

16.7

18.7

20.7

22.7

24.7

26.7

28.7

30.7

32.7

34.7

36.7

44.7

YES

Note2

BPCB mounting pattern

[Specific No.] –* *, (* *)

(27) :Tin plated embossed tape packaging

(57) :Gold plated embossed tape packaging

Note:If the pattern is included in the shaded area and

not treated with resist, it could contact to the

connector contact .

sStraight Pin Header (SMT)

P=2

0.65

B

1.5

No.2

No.1

A

A

1.5

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.

All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
