Part Number:

0191600197

Status:

Active

Description:

M-Cap Wire Connector, Red, for 6-22 AWG Wire

Agency Certification

UL

E32244

General

Product Family

Splices

Series

19160

Crimp Quality Equipment

Yes

Mil-Spec

N/A

Product Name

Wing Lock

Physical

Barrel Type

Closed

Flammability

94V-2

Insulation

Nylon (PA)

Packaging Type

Bag

Temperature Range - Operating

105°C

Wire Insulation Diameter

13.2mm (.52") max

Wire Size AWG

10, 12, 14, 16, 18, 20, 22, 24, 26, 6, 8

Wire Size mm²

16.80 - 0.40

Electrical

Voltage - Maximum

600V

Material Info

Old Part Number

MCAP-R

Reference - Drawing Numbers

Product Specification

PS-19160-001

Sales Drawing

SD-19160-004

EU RoHS

China RoHS

ELV and RoHS

Compliant

REACH SVHC

Not Reviewed

Halogen-Free

Status

Not Reviewed

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Search Parts in this Series

19160Series
