PT2260 V1.4

- 1 -

April, 2006

Remote Control Encoder

PT2260

DESCRIPTION

PT2260 is a remote control encoder paired with either PT2270 or PT2272 utilizing CMOS Technology.

It encodes data and address pins into a serial coded waveform suitable for RF modulation. PT2260 has

drastically reducing any code collision and unauthorized code scanning possibilities.

PT2260 is one of the first generation of Encoder/Decoder ICs that utilizes the unique PTC Technology.

When paired with PT2270, this encoder/decoder (PT2260/PT2270) pair can operate at very wide

temperature range (see Features). Thus, this very important feature enables your Encoder/Decoder to

operate under the worst environmental condition.

FEATURES

• High performance CMOS technology

• Low power consumption

• Very high noise immunity

• Wide operating temperature range: -40℃ ~ 85℃

• 8 or 10 Tri-State code address pins

• 2 or 4 data pins

• Wider range of operating voltage: 1.8 ~ 10.0V

• Single resistor oscillator

• Least external components

APPLICATIONS

• Home/Car security system

• Garage door controller

• Remote fan controller

• Remote control toys
