PT2260 V1.4

- 16 -

April, 2006

Remote Control Encoder

PT2260

Symbol

Min.

Typ.

Max.

A

1.35

-

1.75

A1

0.10

-

0.25

A2

1.25

-

1.65

b

0.31

-

0.51

b1

0.28

-

0.48

c

0.17

-

0.25

c1

0.17

-

0.23

D

9.90 BSC.

E

6.00 BSC.

E1

3.90 BSC.

e

1.27 BSC.

L

0.40

-

1.27

L1

1.04 REF.

L2

0.25 BSC.

R

0.07

-

-

R1

0.07

-

h

0.25

-

0.50

θ

0°

-

8°

θ1

5°

-

15°

θ2

0°

-

-

Notes:

1.

Dimensioning and tolerancing per ANSI Y 14.5M-1994

2.

Controlling Dimension: MILLIMETERS.

3.

Dimension D does not include mold flash protrusions or gate burrs. Mold flash, protrusions or

gate burrs shall not exceed 0.15 mm (0.006 in) per end. Dimension E1 does not include

interlead flash or protrusion. Interlead flash or protrusion shall not exceed 0.25mm per side. D

and E1 dimensions are determined at datum H.

4.

The package top may be smaller than the package bottom. Dimensions D and E1 are

determined at the outermost extremes of the plastic body exclusive of mold flash, tie bar burrs,

gate burrs and interlead flash, but including any mismatch between the top and bottom of the

plastic body.

5.

Datums A & B to be determined at datum H.

6.

N is the number of terminal positions. (N=16)

7.

The dimensions apply to the flat section of the lead between 0.10 to 0.25mm from the lead tip.

8.

Dimension “b” does not include dambar protrusion. Allowable dambar protrusion shall be

0.10mm total in excess of the “b” dimension at maximum material condition. The dambar cannot

be located on the lower radius of the foot.

9.

This chamfer feature is optional. If it is not present, then a pin 1 identifier must be located within

the index area indicated.

10. Refer to JEDEC MS-012, Variation AC.

JEDEC is the registered trademark of JEDEC SOLID STATE TECHNOLOGY ASSOCIATION.
