B-9

CAGE Code 06324

507-059

for MIL-C-81659 Connectors

Dash

No

02

03

04

05

06

TABLE I: CABLE ENTRY

J

Max

.97 (24.6)

1.05 (26.7)

1.16 (29.5)

1.22 (31.0)

1.34 (34.0)

E

Entry

.25

(6.4)

.37

(9.4)

.50 (12.7)

.62 (15.7)

.75 (19.1)

F Dia

Max

.55 (14.0)

.67 (17.0)

.80 (20.3)

.92 (23.4)

1.05 (26.7)

G Dia

Max

.69 (17.5)

.79 (20.1)

.92 (23.4)

1.04 (26.4)

1.17 (29.7)

Min

.125

(3.2)

.250

(6.4)

.250

(6.4)

.375

(9.5)

.500 (12.7)

Max

.250

(6.4)

.375

(9.5)

.500 (12.7)

.625 (15.9)

.750 (19.1)

Cable Range

Basic Part No.

Finish

B = Cadmium Plate/Olive Drab

M = Electroless Nickel

N = Cadmium Plate/Olive Drab over Nickel Plate

NF = Cadmium Olive Drab over Electroless

Nickel (1000 Hour Salt Spray)

507-059 NF 06 G L

Entry Location

L = Left Side Entry

R = Right Side Entry

Omit for Top Entry

L = Strain Relief

G = Gland Nut

Dash No. (Table I)

2.50 (63.5)

Max Typ.

Note 3

E

1.715 (43.6) Max

1.377 (35.0)

1.50

(38.1)

.938

(23.8)

Typ.

1.195

(30.4)

Max

Typ.

1.437 (36.5)

T Top

Entry

R Right

Entry

L Left

Entry

.407

(10.3)

G

F

Style G Nut

Knurl

Style Mfr.

Option (Typ)

.390 (9.1) Ref

Shrink Boot

Accomodation

See Note 3

1.500 (38.1)

.875

(22.2)

J Max

Cable

Range

.850 (21.6)

Max

Style L Strain

Relief

1. Metric dimensions (mm) are indicated in

parentheses.

2. Material/Finish:

Backshell, Adapter, Clamp, Tag Ring

Body = Al Alloy/Finish Per Option

Tag Ring Nut = Al Alloy/Gold Iridite

Tag Ring Spring = Beryllium Copper/

Gold Plate

Friction Washer = Teflon/N.A.

Clamp Hardware = Cres/Passivate

3. Style “L” strain relief option will be supplied

less shrink boot accomodation and 2.50

max height will be 2.36 max.
