CP41B-RDS/ADS (40 degrees)

CP41B-RFS/AFS (70 degrees)

CP41B-RHS/AHS (100 degrees)

Data Sheet

This revolutionary package design allows the lighting designer to reduce the number of LEDs

required and provide a more uniform and unique illuminated appearance than with other

LED solutions.

This is possible through the efficient optical package design and high-current capabilities.

The low-profile package can be easily coupled with reflectors or lenses to efficiently distribute

light and provide the desired lit appearance. This product family employs red and amber LED

materials, which allows designers to match the color of many lighting applications like vehicle

signal lamps, channel letters and gaming-equipment lighting.

FEATURES

•

Size (mm): 7.6 x 7.6

•

Color and Typical Dominant Wavelength (nm):

»

Red (628)

»

Amber (591)

•

Luminous Flux (mlm)

»

CP41B-RDS (4400 - 11000)

»

CP41B-RFS (4400 - 11000)

»

CP41B-RHS (4400 - 13200)

»

CP41B-ADS (4400 - 11000)

»

CP41B-AFS (5500 - 13200)

»

CP41B-AHS (5500 - 13200)

•

Lead-Free

•

RoHS Compliant

APPLICATIONS

•

Channel Letter

•

Amusement
