Elektronische Bauelemente

BAS40WS

Surface Mount Schottky Barrier Diodes

01-August-2009 Rev. A

Page 1 of 2

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURES

Low Turn-on Voltage

Fast Switching

PN Junction Guard for Transient and ESD Protection

Designed

for Surface Mount Application

Plastic

Material –UL Recognition Flammability

Classification

94V-O

MARKING

43

Parameter

Symbol

Ratings

Unit

Peak Repetitive Peak reverse voltage

Working Peak Reverse Voltage

DC Blocking Voltage

40

V

Forward Continuous Current

200

mA

Peak Forward Surge Current, t≦1.0 s

600

mA

Thermal Resistance Junction−to−Ambient

625

°C/W

Power Dissipation

200

mW

Junction, Storage Temperature

-55 ~ +150

°C

Parameters

Symbol

Min.

Typ.

Max.

Unit

Test Conditions

Reverse Breakdown Voltage

40

-

-

V

μA

Reverse Current

-

20

200

nA

-

-

380

mV

-

-

500

mV

Forward Voltage

-

-

1000

mV

Diode Capacitance between

Terminals

-

4.0

5.0

pF

Reverse Recovery Time

-

5

nS

Ω

Millimeter

Millimeter

REF.

Min.

Max.

REF.

Min.

Max.

A

1.05 REF.

E

0.080

0.180

B

0.20 REF.

F

1.15

1.45

C

0.80

1.00

G

1.60

1.80

D

0.25

0.40

H

2.30

2.70

Cathode Band

G

E

A

J

F

D

H

C

B

1

2

SOD-323
