(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Type code : S ( Standard )

(a) Series code

2. CONFIGURATION & DIMENSIONS :

A

4. MATERIALS :

SUPERWORLD ELECTRONICS (S) PTE LTD

(a) Core : Ceramic U core

(c) Terminal Metallization : Ag + Ni + Au

3. SCHEMATIC :

(d) Inductance code : 5N6 = 5.6nH

(e) Tolerance code : G = ±2%, J = ±5%, K = ±10%

SCI1008S SERIES

WIREWOUND CHIP INDUCTORS

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

22.06.2010

PCB Pattern

2.92 Max.

2.03 Max.

0.65 Ref.

2.79 Max.

a

b

(b) Wire : Enamelled Copper Wire

0.51 Ref.

1.52 Ref.

2.54 Ref.

1.02 Ref.

2.03 Ref.

BC

D

E

F

G

H

c

S C I 1 0 0 8 S - 5 N 6 K F

I

J

I

E

D

C

B

Unit:m/m

1.27 Ref.

J

I

(f) F : RoHS Compliant

(f)
