FEATURES / BENEFITS

Onboard drive accepts low voltage input

Long life, up to 60,000 hours

Low 1.5 watt power consumption

Low profile - ADA compliant

Optional niche mounting box available for direct burial

in concrete or ground

ETL listed to UL2108 standards for dry, damp or wet

locations

IP67 rated for interior or exterior use

40 lumen output for white.

Consult factory for additional options

OPERATING CONDITIONS

Runs off 8-24 VDC or 10-14 VAC

Current draw = 0.128A@ 12 VDC, 1.5 watts

MDEXLUMGU2_B

Dialight Corporation

1501 Route 34 South • Farmingdale, NJ 07727 USA

Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com

MATERIALS/FINISH

Anodized aluminum base and “snap-on” top cover

PMMA lens

PTFE Lead Wires 20” (508mm) long, 20 AWG

APPLICATIONS

Ideal for any difficult to maintain location low level pathway

systems, architectural accent, staircases, decks, kitchens,

etc. Easily mounts to wood, tile, stone, glass,

stainless steel, etc

PRIVATE LABEL

OEM PROGRAM

Multiple modules can be connected in parallel for

longer runs off a single supply.

Ambient Temperature limits -30ºC to +55ºC

(-22ºF to +131ºF)

Dialight Lumidrives

York House • Weatherby Road • Long Marston, York, YO26 7NH

Tel: 0845 6346161 • Fax: 0845 6346160 • www.dialight.com

ORDERING INFORMATION

Guida 2 Base

Series - Cover Type

GU - Dome

GU - Flush

GU - Eyelid

Base & cover purchased separately

Guida 2 Covers

LED Color (A)

Optical Pattern (B)

Version (CC)

C = Cool White 5300K / *40 lumen min

D = Diffused

“Blank” =

European Market

Version

N = Neutral White 4000K / *40 lumen min

S = Spot

W = Warm White 3050K / *40 lumen min

R = Red

US =

North America

Version

G = Green

B = Blue

A = Amber

GU-MBX = Euro version

GU-MBX-US = US version

Mounting Box

acceptable ambient temp will be approximately 25-30% lower, depending on

thermal conductivity of mounting surface and lens type.

GU2 SERIES

SINGLE LED MODULE

DOME

FLUSH

EYELID
