Low-Power LCD Microcontroller

_____________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(VDD = VDD(MIN) to VDD(MAX), VDDIO = 2.7V to 3.6V, TA = -40°C to +85°C.) (Note 1)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional

operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to

absolute maximum rating conditions for extended periods may affect device reliability.

Voltage Range on Any Pin Relative to

Ground Except VDD .................................-0.5V to (VDDIO + 0.5)V

Voltage Range on VDD Relative to Ground .........-0.5V to +2.75V

Voltage Range on VDDIO Relative to Ground........-0.5V to +3.6V

Operating Temperature Range ...........................-40°C to +85°C

Storage Temperature Range .............................-65°C to +150°C

Soldering Temperature ..........................Refer to the IPC/JEDEC

J-STD-020 Specification.

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

32k x 16 flash

1.8

2.5

2.75

Core Supply Voltage

VDD

Flash programming

2.25

2.5

2.75

I/O Supply Voltage

VDDIO

VDD

3.6

VDD Slew Rate

VDD rising (Note 2)

225

mV/ms

IDD1

/1 mode

6.0

9.2

IDD2

/2 mode

5.6

8.6

IDD3

/4 mode

3.4

5.1

IDD4

/8 mode

1.9

2.9

IDD5

PMM1 mode

0.5

0.7

Rev A2

4.8

7.6

Active Current,

fHFIN = 14MHz

(Note 3)

IDD6

PMM2 mode;

32KIN = 32.768kHz

Rev A3

0.1

0.95

IDD1

/1 mode

6.5

10.4

IDD2

/2 mode

5.9

9.6

IDD3

/4 mode

3.8

6.2

IDD4

/8 mode

2.2

3.8

IDD5

PMM1 mode

0.6

1.4

Rev A2

4.8

7.6

Active Current,

fHFIN = 20MHz

(Note 3)

IDD6

PMM2 mode;

32KIN = 32.768kHz

Rev A3

0.1

0.95

Execution from flash memory, 20MHz,

VDD = 2.2V, TA = +25°C

5.1

Execution from flash memory, 8MHz,

/8 mode, VDD = 2.2V, TA = +25°C

0.85

Execution from flash memory, 8MHz,

PMM1 mode, VDD = 2.2V, TA = +25°C

0.19

Execution from RAM, 8MHz,

/8 mode, VDD = 2.2V, TA = +25°C

0.30

Active Current

Execution from RAM, 1MHz,

/1 mode, VDD = 2.2V, TA = +25°C

0.14

-40°C < TA < +25°C

0.7

Stop-Mode Current

ISTOP(VDD)

TA = +85°C

550

μA

Digital I/O Supply Current

IDDIO

RTC enabled; HFIN

14MHz;

all I/O disconnected

μA
