CT01-040-R datasheet(1/1 Pages) ICE

部件名	CT01-040-R

功能描述	SMT Current Sense Transformer

PDF	1 Pages

Scroll/Zoom	100%

制造商	ICE [ice Components, Ins.]

网页	http://www.icecomponents.com

标志

1 / 1 page

Specifications subject to change without notice.

800.729.2099 tel

www.icecomponents.com

Features

•

Low Profile

•

Full Selection of Turns Ratios

•

Primary Rated for 10A

•

Frequency Range up to 1MHz

•

Suitable for Pick And Place Applications

•

Withstands Solder Reflow

Applications

•

DC/DC Converters

•

AC/DC Converters

Mechanical

Electrical Specifications

CT01-020-R

CT01-030-R

CT01-040-R

CT01-050-R

CT01-060-R

CT01-070-R

CT01-100-R

CT01-125-R

CT01-200-R

Part

Number

0.40

0.60

0.80

1.50

1.70

3.10

5.50

6.50

35.00

Rs

(

Ω, max.)

500

Hi-Pot

1. Tested @ 10kHz, 0.1Vrms.

2. Electrical specifications at 25ºC.

3. Operating temperature range:

-40ºC to +130ºC.

4. Meets UL 94V-0.

5. Terminating resistor for 1 volt

out with 6 Amps AC flowing

through the primary.

Ls

1

(μH, min.)

102

230

408

638

920

1250

1680

2620

6700

3.33

5.00

6.67

8.33

10.00

11.67

16.67

20.83

33.33

Terminating

5

Resistor (

Ω)

Turns

Ratio

1:20

1:30

1:40

1:50

1:60

1:70

1:100

1:125

1:200

Packaging

•

Reel Diameter: 13"

•

Reel Width:

16mm

•

Pieces Per Reel: 1000

Recommend PCB Layout

Schematic

��

�

��

0.6

CT01 Series

SMT Current Sense Transformer

78

(02/08) CT01-1
