LB1663, 1663M, 1666

No.2552-2/5

Allowable Operating Conditions at Ta = 25

°C

Parameter

Symbol

Conditions

Ratings

Unit

Input current range

ICC

6.0 to 50.0

Common-mode input voltage range

VICM

0 to VIN-1.5

Electrical Characteristics at Ta

= 25°C, ICC = 10mA

Ratings

Parameter

Symbol

Conditions

min

typ

max

Unit

VOLM

Output limit voltage

VO (sus)

IO = 0.1A

VO (sat)1

IO = 0.5A

0.95

1.20

VO (sat)2

IO = 1.0A

1.15

1.50

Output saturation voltage

VO (sat)3

IO = 1.5A

1.40

2.00

VIN input voltage

VIN

ICC = 7.0mA

6.4

6.7

7.0

Amp input offset voltage

Voff

-7

Amp input bias current

IBA

-250

RD output saturation voltage

VRD (sat)

IRD = 5mA

0.1

0.2

C flow-out current

IC1

2.1

3.0

3.9

μA

LB1663, 1663M

0.31

0.44

0.59

μA

C discharge current

IC2

LB1666

0.21

0.30

0.39

μA

VTH1

0.77

0.8VIN

0.83

Comparator input threshold voltage

VTH2

0.42

0.45VIN

0.48

Package Dimensions

unit : mm (typ)

3098D

[LB1663]

3097B

[LB1663M]

SANYO : DIP10S(300mil)

9.14

0.95

0.48

(1.01)

1.78

SANYO : MFP16FS(300mil)

12.5

1.35

0.35

1.0

1.5

(2.7)

0.15
