For surface mounted application

Glass passivated chip junction

Low forward voltage drop

High current capability

Easy pick and place

High surge current capability

S3XB = Specific Device Code

G

= Green Compound

Y

= Year

M

= Work Month

Maximum Ratings and Electrical Characteristics

Rating at 25 ℃ ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%

50

100

200

400

600

800

1000

V

35

70

140

280

420

560

700

V

50

100

200

400

600

800

1000

V

Trr

uS

Cj

pF

Plastic material used carries Underwriters

Laboratory Classification 94V-0

Dimensions in inches and (millimeters)

Case: Molded plastic

Peak Forward Surge Current, 8.3 ms Single Half Sine-

wave Superimposed on Rated Load (JEDEC method)

Maximum Average Forward Rectified Current

@TL=75℃

3A

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Reverse Recovery Time (Note 2)

Version:E11

Typical Thermal Resistance

Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.

Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle

10

- 55 to + 150

Operating Temperature Range

Storage Temperature Range

- 55 to + 150

uA

40

10

250

Typical Junction Capacitance (Note 3)

1.5

S3AB - S3MB

3.0AMPS Surface Mount Rectifiers

Marking Diagram

SMB/DO-214AA

Features

Mechanical Data

High temperature soldering:

260℃/10 seconds at terminals

Weight: 0.093 grams

Polarity: Indicated by cathode band

Type Number

Packing: 12mm tape per EIA STD RS-481

S3

AB

S3

BB

Terminals: Pure tin plated, lead free

Green compound with suffix "G" on packing

code & prefix "G" on datecode

A

Maximum Instantaneous Forward Voltage (Note 1)

@ 3 A

1.15

V

80

Symbol

S3

DB

Unit

S3

GB

S3

JB

S3

KB

S3

MB

Pb

RoHS

COMPLIANCE
