UNISONIC TECHNOLOGIES CO., LTD

IMZ2A

DUAL TRANSISTOR

www.unisonic.com.tw

1 of 3

QW-R215-002,C

POWER MANAGEMENT

(DUAL TRANSISTOR)

FEATURES

* Both a 2SA1037AK chip and 2SC2412K chip in a SMT package.

EQUIVALENT CIRCUITS

Lead-free:

IMZ2AL

Halogen-free: IMZ2AG

ORDERING INFORMATION

Ordering Number

Pin Assignment

Normal

Lead Free

Halogen Free

Package

123

45

6

Packing

IMZ2A-AG6-R

IMZ2AL-AG6-R

IMZ2AG-AG6-R

SOT-26

C2 E2 C1 E1 B1 B2 Tape Reel

IMZ2A-AL6-R

IMZ2AL-AL6-R

IMZ2AG-AL6-R

SOT-363

C2 E2 C1 E1 B1 B2 Tape Reel

MARKING
