EMI Core

7

EMI Cores

Ring Type

●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.

●Please request for a specification sheet for detailed product data prior to the purchase.

●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.

9634ESDVOL09E1003E1

Dimensions（mm）

Model

ESD-SR-160H

ESD-SR-250H

A

19.5

30

C

19.5

30

D

46.5

53

E

38.5

42

Weight(g)

23

63

Color of case

black

black

φB

∼9

∼13

Snap-on Cores for Round Cables with High Heat

Resistance and Cable Holding Mechanism

ESD-SR-H Series

[RoHS Compliant]

Snap-on Cores for Round Cables with High Heat

Resistance and Cable Holding Mechanism

ESD-SR-H Series

[RoHS Compliant]

Snap-on Cores for Round Cables with High Heat

Resistance and Cable Holding Mechanism

ESD-SR-H Series

[RoHS Compliant]

Shape and Dimensions

Impedance vs. Frequency

[mm]

D

E

A

B

1

1000

100

10

1

10

100

1000

Frequency (MHz)

ESD-SR-H

ESD-SR-160H

ESD-SR-250H

①Wider operational temperature range.

40℃∼

125℃

)

②Holding mechanisms provided

 (Fixing of cables / enclosures with fixing bands possible)

③Our unique core material enables high performance in high frequency range

 audio-visual equipment, consumer electronics

Features

Applications
