DC Line Filters VOL.10

●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.

●Please request for a specification sheet for detailed product data prior to the purchase.

●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.

9634DCLVOL10E1106E2

SMD Type

Common Mode Power Line

1

2

3

4

(1.5)

(1.5)

(7.2)

(6.3)

9.0±0.2

8.0±0.2

9.7 max.

8.7 max.

1

3

2

4

Circuit Diagram

Shape and Dimensions

SBS9080 Series

[RoHS Compliant]

• Tape and Reel Dimensions (see page 44)

• Precautions (see page 43)

SBS9080-509T

50

5.0

0.9

15

–25 to +50

SBS9080-524T

50

5.0

2.4

15

–25 to +50

Rated voltage

Rated current

Inductance

DC resistance

Operating

Model

(at 100KHz)

(m /line)

temperature range

DC (V)

DC (A)

(

μH) min.

max.

(˚C)

SBS9080 Series

[RoHS Compliant]

• Withstanding voltage: 125V DC for one minute between lines

• Insulation resistance: More than 10M

(100V DC, between lines)

10000

1000

100

10

1

1

10

100

1000

Frequency (MHz)

524T

509T

Impedance vs. Frequency

4.0

4.0

2.0

Recommended Land Pattern

[mm]

[mm]
