DC Line Filters VOL.10

●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.

●Please request for a specification sheet for detailed product data prior to the purchase.

●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.

9634DCLVOL10E1106E2

DIP Type

Normal Mode

3.0 max.

40±3.0

10.0±0.5

40±3.0

5.08±0.2

a

40±3.0

a

5.08±0.2

bB-6-22B

bB-6-31B

2.5 max.

a=2.54±0.3

3.0 max.10±0.5

13.4 max.

(Clock pulse oscillating section)

bB-1,3,4,5,7

(a)max.

bB-8,9,10

8.0max.

ø0.4

Shape and Dimensions

Model

(a)

(b)

(c)

B-1

5.5

5

9

B-3

95

10

B-4

10.5

5

9

B-5

11

5

9

B-7

65

9

Bead Inductors

(Winding Type)

[RoHS Compliant]

B-1

B-20F-28

Teflon wire (ø0.26 : single) / Color: White

2T

B-3

B-20L-48B

Teflon wire (ø0.51 : single) / Color: Red

2T

B-4

B-20L-44

Teflon wire (ø0.26 : single) / Color: White

2T

B-5

B-20L-44

Teflon wire (ø0.26 : single) / Color: White

3T

B-7

B-20F-28

Teflon wire (ø0.32 : single) / Color: Green

2T

B-8

B-20L-48B

Teflon wire (ø0.4 : single) / Color: Blue

2T

B-9

B-20L-48B

Teflon wire (ø0.4 : single) / Color: Yellow

3T

B-10

B-20L-48B

Teflon wire (ø0.4 : single) / Color: Black

4T

B-6-22B

—

Soft copper wire (ø0.6)

—

B-6-31B

—

Soft copper wire (ø0.6)

—

Model

CoreWire

No. of turns

Bead Inductors

(Winding Type)

[RoHS Compliant]

1

10

1000

100

Frequency (MHz)

B-1

1

10

100

1000

1

10

1000

100

Frequency (MHz)

B-3

1

10

100

1000

Impedance vs. Frequency

[mm]
