DC Line Filters VOL.10

●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.

●Please request for a specification sheet for detailed product data prior to the purchase.

●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.

9634DCLVOL10E1106E2

DIP Type

Common Mode Signal Line

ESD-H-12E

ESD-R-12C

16

20

5

25

7

UL1007 AWG26 (ø0.4)

Bi-filar winding

Up to 300

ESD-H-14U

ESD-R-14A

17.5

7

5

15

10

UL1609 AWG26 (ø0.4)

Bi-filar winding

Up to 100

ESD-H-14NU

ESD-R-14C2

17.5

7

5

15

10

UL1609 AWG26 (ø0.4)

Bi-filar winding

Up to 300

Model

Core

Dimensions (mm)

No. of turns

Wire

Winding status

Frequency range

ABC

D

(MHz)

Toroidal Cores with

Wound Cables

[RoHS Compliant]

Toroidal Cores with

Wound Cables

[RoHS Compliant]

50

10

5K

10K

1K

500

100

14U

14NU

1

1K

100

10

12E

5

10

50

100

500

1

Frequency (MHz)

5

10

50

100

500

1

Frequency (MHz)

Impedance vs. Frequency

bESD-H Series

A

B

Shape and Dimensions

Circuit Diagram

• Recommended soldering conditions: 350±10˚C, 2 to 3 sec.

• Rated current:1A

• Rated Voltage: 125V
