12 / 42 page

Part Number

Available Colours

Y-ConIP20Lock-Clip-1

Red

(R-030)

Y-ConIP20Lock-Clip-2

Orange (OR-005)

Y-ConIP20Lock-Clip-3

Yellow (GE-013)

Y-ConIP20Lock-Clip-4

Green (GR-041)

Y-ConIP20Lock-Clip-5

Blue

(BL-012)

Y-ConIP20Lock-Clip-6

Grey

(G-038)

Y-ConIP20Lock-Clip-7

White (W-040)

Series

Side 1

Side 2

Cable Length

Wiring

Series

Available Colours

Y-ConC- R ** 2U - **** - **** - *

Y-ConIP20Lock-Clip

- *

Part Number Example

Part Number (Details)

Outline Dimensions

TECHNISCHE ÄNDERUNGEN VORBEHALTEN – MASSE IN MILLIMETER

Description:

IP20Lock 90° molded cable assembly,

with option for an additional colour coded locking

slider for increased mechanical retention.

Available with various Y-Con plug and cable

combinations

IP20Lock 90° umspritzte Kabelkonfektion mit optionalem-

zusätzlichem Schiebeverschluss (farbcodiert) für verbesserte

mechanische Rückhaltekraft. Erhältlich in verschiedenen

Y-Con Stecker- und Kabelkombinationen

Material:

PA66

Specifications:

Operating Temp.: -20°C ~ +120°C

Betriebstemp.

For Part number details: see page 12

For Holding frames: see page 9

Description:

Colour coded locking slider for

Y-ConC-R**2U-****-***** - *

Farbcodierter Schiebeverschluss für

Y-ConC-R**2U-****-*****

- *

Material:

PA66

Specifications:

Operating Temp.: -20°C ~ +120°C

Betriebstemp.

IP20 Protected Components
