Description:

100 Mbit, Cat 5 (Cat 5e), digital signal cable.

Silicon and CFC free

100 Mbps, Cat 5 (Cat 5e), Kabel für digitale Signale.

Silikon- und FCKW frei

Part Number Y-ConCable-1

Part Number Y-ConCable-4

Part Number Y-ConCable-2

Part Number Y-ConCable-7

for ProfiNet

Part Number Y-ConCable-3

Part Number Y-ConCable-10

Series

See table below

Y-ConCable - *

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

2 x 2

2

PVC

-20°C ~ +80°C

6.9mm

No

125mm multiple turns

max. 100,000

AWG 24/7

AWG 22/19

Green

(+0.1)

35mm single turn

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

2 x 2

2

PUR

-20°C ~ +80°C

6.8mm

Yes

70mm multiple turns

max. 1 million

AWG 26/7

AWG 22/7

Green

(+0.2)

35mm single turn

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

4 *

0

PUR

-20°C ~ +80°C

6.8mm

Yes

102mm multiple turns max. 2.5 million

AWG 22/7

Green

(+0.2)

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

2 x 2

0

PVC

-20°C ~ +80°C

6.85mm

No

min. 50mm single turn

-

AWG 24/7

Grey

(+/-0.15)

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

4 x 2

0

PUR

-20°C ~ +70°C

6.8mm

Yes

68mm

max. 1 million

AWG 26/7

Green

(+0.1/-0.3mm)

Signal

Power

Jacket

Temp.

Cable

OD

Cable

Chain

Bending

Radius

Bending

Cycles

4 x 2

2

PUR

-20°C ~ +70°C

6.9mm

Yes

70mm multiple turns

max. 1 million

AWG 26/7

AWG 23/19

Green

(+0.1)

Suitable for Y-ConPlug-21

Suitable for Y-ConPlug-11

Suitable for Y-ConPlug-21

Suitable for Y-ConPlug-41

Suitable for Y-ConPlug-51

Suitable for Y-ConPlug-15
