TECHNISCHE ÄNDERUNGEN VORBEHALTEN – MASSE IN MILLIMETER

29

Y-ConCoupler-10

Y-ConCoupler-11

Description:

IP67 coupler module (w/o electronics) screw mount,

guide rails for modular assembly

IP67 Kupplungsmodule (ohne Elektronik) mit Schraubhalterung

und Führungsschienen für modularen Aufbau

Material:

PBT, UL94V-0

Specifications:

Operating Temp.: -30°C ~ +120°C

Betriebstemp.

Description:

non-blocking, full or half duplex, auto-negotiated data control, screw mounted

IP67 Ethernet-Schalter*,10BaseT/100BaseTX, 7 Datenports, 1 Stromversorgungsbuchse, unmanaged, Store / Forward,

non-blocking, Voll- oder Halbduplexbetrieb, Auto-negotiated Data control, Wandbefestigung

Material:

Housing

Aluminium

Gehäuse

Flange

PBT, UL94V-0

Flansch

Specifications

Operating Temp.: -40°C ~ +85°C

Betriebstemp.

Electrical specifications (on request)

Industrial Peripherals

* i.a.w. IEEE 802.3

IEEE 1588

Part Number

No. of Y-ConFlange-10*

Colour

Y-ConCoupler-10

2

Blue

Y-ConCoupler-10-B

2

Black

Y-ConCoupler-11

1 (plus cable gland

∅5.0 -9.0mm)

Blue

Y-ConCoupler-11-B

1 (plus cable gland

∅5.0 -9.0mm)

Black

Series

Design Number

(see table below)

No Mark = Blue

B = Blac

Y-ConCoupler - **

*

Series

Design Number

Y-ConSwitch-1U7P
