For further information contact your local STMicroelectronics sales office.

September 2012

Doc ID 023588 Rev 2

1/3

3

STM32F4-NETMF

Microsoft .NET Micro Framework environment

for STM32F4 microcontrollers

Data brief

Features

– STM32F407VG MCU

– Ethernet connector and embedded lwIP

Stack: HTTP, TCP, UDP, DHCP, ICMP

(no separate Ethernet module needed)

– 8 Gadgeteer sockets for: GPIO (34x), CAN,

SPI (2x), I2C, UART (4x), AD (3x), DA,

PWM (3x)

– Integrated micro USB connector

(no separate USB client module needed)

– 2 pushbutton switches (Reset and User)

– Embedded 8-MByte Flash memory (SPI)

– Power LED (green) and RGB User LED

– Serial Wire Debug (SWD) and boot mode

selection on the manufacturer-specific

connector (Z)

– Low power modes

– 100 % open source hardware and software

Figure 1.

STM3240G-ETH/NMF evaluation

board

– STM32F407VG MCU

– 9 Gadgeteer sockets for: GPIO (34x), CAN,

SPI (2x), I2C, UART (4x), AD (3x), DA,

PWM (3x), USB Device/Host (independent

from the second USB port, described

below)

– Integrated micro USB connector

(no separate USB client module needed)

– 2 pushbutton switches (Reset and User)

– Embedded 8-MByte Flash memory (SPI)

– Power LED (green) and RGB User LED

– Serial Wire Debug (SWD) and boot mode

selection on the manufacturer-specific

connector (Z)

– Low power modes

– 100 % open source hardware and software

Figure 2.

STM3240G-USB/NMF evaluation

board

www.st.com
