Series AM2D-RZ

2 Watt | DC-DC Converter

www.aimtec.com

Tel: +1 514 620 2722

Toll free: + 1 888 9 AIMTEC

(924 6832)

F 051e R12.A

3 of 5

North America only

Output Specifications (continued)

Parameters

Conditions

Typical

Maximum

Units

Load voltage regulation

Load 10~100%

±5

%

Temperature coefficient

±0.02

%/

Ripple & Noise

20MHz Bandwidth

50

mV p-p

Minimum Load Current

10

% of Max

General Specifications

Parameters

Conditions

Typical

Maximum

Units

Switching frequency

100% load

70

KHz

Operating temperature

-40 to +85

Storage temperature

-40 to +125

Maximum case temperature

100

Cooling

Free Air Convection

Humidity

95

% RH

Case material

Plastic UL94V-0

Weight

2.8

g

Dimensions (L x W x H)

0.76 x 0.28 x 0.39 inch

19.50 x 7.20 x 10.00 mm

MTBF

>1.9 Mhrs (MIL-HDBK -217F, Ground Benign, t=+25

Maximum soldering temperature

1.5mm from case for 10 sec

260

Safety Specifications

Parameters

Agency Approval

CE

Standards

EN55022: 2006 + A1: 2007, Class B

EN55024: 1998 + A1: 2001 + A2:2003

IEC61000-4-2:2008

IEC61000-4-3: 2006 + A1: 2007

IEC61000-4-4, 2004

IEC61000-4-6: 2008

IEC61000-4-8: 1993 + A1:2000

Pin Out Specifications

Pin

1000 VDC

3000 VDC

Single

Dual

Single

Dual

1

+ V Input

+ V Input

+ V Input

+ V Input

2

- V Input

- V Input

- V Input

- V Input

4

- V Output

- V Output

No pin

No pin

5

No pin

Common

-V Output

-V Output

6

+ V Output

+ V Output

No pin

Common

7

No pin

No pin

+V Output

+V Output
