Description

• Halogen free, lead free, RoHS compliant

• 125°C Maximum total temperature operation

• 10.5 x 8.0 x 7.0mm Maximum surface mount package

• Ferrite core material

• Controlled DCR tolerance for sensing circuits

• Inductance Range from 150nH to 470nH

• Current range from 23.5 to 75 Amps

• Frequency range up to 2MHz

High Current, High Frequency, Power Inductors

Flat-Pac™ FP1007R6 Series

0912

BU-SB12795

Page 1 of 4

Data Sheet: 10007

HALOGEN

HF

FREE

Pb

Applications

• Multi-phase regulators

• Voltage Regulator Modules (VRMs)

• Desktop and server VRMs and EVRDs

• Notebook regulators

• Data networking and storage systems

• Graphics cards and battery power systems

• Point-of-Load modules

• DCR Sensing

Environmental Data

• Storage temperature range: -40°C to +125°C

• Operating temperature range: -40°C to +125°C

(ambient + self-temperature rise)

• Solder reflow temperature: J-STD-020D compliant

Packaging

• Supplied in tape-and-reel packaging, 700 parts per

13 inch diameter reel

Product Specifications

Part

DCR @20°C

(nH)

(nH)

(Amps)

(Amps)

(Amps)

(mΩ)

FP1007R6-R15-R

150

108

75.0

60.0

FP1007R6-R18-R

180

129

60.0

50.0

FP1007R6-R22-R

220

158

50.0

40.0

FP1007R6-R27-R

270

194

61

41.0

33.0

0.29 ± 5%

348.8

FP1007R6-R33-R

330

237

33.0

26.5

FP1007R6-R39-R

390

280

28.0

22.5

FP1007R6-R47-R

470

338

23.5

19.0

Derating is necessary for AC currents. PCB layout, trace thickness and width,

air-flow, and proximity of other heat generating components will affect the

temperature rise. It is recommended that the temperature of the part not

exceed 125°C under worst case operating conditions verified in the end

application.

6. K-factor: Used to determine Bp-p for core loss (see graph).

L: (Inductance in nH), ∆I (peak-to-peak ripple current in Amps).

7. Part Number Definition: FP1007R6-Rxx-R

FP1007R6 = Product code and size

Rxx= Inductance value in uH, R = decimal point

-R suffix = RoHS compliant
