0912

BU-SB12795

Page 2 of 4

Data Sheet: 10007

24.0

±0.30

1.75

11.5

1.5 dia

1.5 dia

4.0

2.0

8.1

12.0

7.1

10.60

2

1

A

A

SECTION A-A

Supplied in Tape-and-Reel packaging, 700 parts per 13 inch diameter reel.

The nominal DCR is measured from point "A" to point "B"

Part Marking: Coiltronics Logo, 1007R6, Rxx = Inductance value in µH. (R = Decimal point) wwllyy = Date code R = Revision level

Tolerance are ±0.15mm unless otherwise specified.

Soldering surfaces to be coplanar within 0.1016mm.

PCB tolerance ±0.1mm unless otherwise specified.

Packaging Information - mm

0

10

20

30

40

50

60

0.0

0.4

0.8

1.2

1.6

2.0

Total Loss (W)

Temperature Rise vs. Total Loss

Dimensions - mm
