Electrical Characteristics (23º)
MPTS1210
Part
Number
Hold
Current
Trip
Current
Rated
Voltage
Max
Current
Typical
Power
Max Time to Trip
Resistance
Current
Time
RMIN
R1MAX
IH, A
IT, A
VMAX, Vdc
IMAX, A
Pd, W
Amp
Sec
Ω
Ω
MPTS1210L005R
0.05
0.15
60
10
0.60
0.25
3.00
3.600
50.000
MPTS1210L010R
0.10
0.25
60
10
0.60
0.50
1.50
1.600
15.000
MPTS1210L020R
0.20
0.40
30
10
0.60
8.00
0.02
0.800
5.000
MPTS1210L035R
0.35
0.70
16
40
0.60
8.00
0.20
0.320
1.300
MPTS1210L050R
0.50
1.00
16
40
0.60
8.00
0.10
0.250
0.900
MPTS1210L075R
0.75
1.50
8
40
0.60
8.00
0.10
0.130
0.400
MPTS1210L110R
1.10
2.20
6
100
0.80
8.00
0.30
0.060
0.210
MPTS1210L150R
1.50
3.00
6
100
0.80
8.00
0.50
0.040
0.110
MPTS1210L175R
1.75
4.00
6
100
0.80
8.00
0.60
0.020
0.080
MPTS1210L200R
2.00
4.00
6
100
0.80
8.00
1.00
0.015
0.070
IH=Hold current-maximum current at which the device will not trip at 23ºC still air.
IT=Trip current-minimum current at which the device will always trip at 23ºC still air.
V MAX=Maximum voltage device can withstand without damage at its rated current (I MAX)
I MAX= Maximum fault current device can withstand without damage at rated voltage (V MAX).
Pd=Typical power dissipated-type amount of power dissipated by the device when in the tripped state in 23ºC still air
environment.
RMIN=Minimum device resistance at 23ºC prior to tripping.
R1MAX=Maximum device resistance at 23ºC measured 1 hour after tripping or reflow soldering of 260ºC for 20 seconds.
Termination pad characteristics
Termination pad materials: Pure Tin
MPTS Series
Polymeric PTC
Rev.7
