S3AB THRU S3MB

SURFACE MOUNT GENERAL RECTIFIER

Reverse Voltage - 50 to 1000 Volts

Forward Current - 3.0 Ampere

The plastic package carries Underwriters Laboratory

Flammability Classification 94V-0

For surface mounted applications

Low reverse leakage

Built-in strain relief,ideal for automated placement

High forward surge current capability

High temperature soldering guaranteed:

250 C/10 seconds at terminals

FEATURES

MECHANICAL DATA

●

Maximum Ratings and Electrical Characteristics @T

A=25°C unless otherwise specified

Characteristic

Symbol

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

VR

50

100

200

400

600

800

1000

V

RMS Reverse Voltage

VR(RMS)

35

70

140

280

420

560

700

V

Average Rectified Output Current @TL = 75°C

I O

3.0

A

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave superimposed on

rated load (JEDEC Method)

IFSM

100

A

Forward Voltage

@IF = 3.0A

VFM

1.10

V

Peak Reverse Current

@TA = 25°C

At Rated DC Blocking Voltage

@TA = 125°C

IRM

5.0

250

µA

Typical Junction Capacitance (Note 2)

Cj

60

pF

Typical Thermal Resistance (Note 3)

R JL

13

Operating and Storage Temperature Range

Tj, TSTG

-55 to +150°C

Note: 1. Measured with IF = 0.5A, IR = 1.0A, Irr = 0.25A,

2. Measured at 1.0 MHz and applied reverse voltage of 4.0 V DC.

3. Mounted on P.C. Board with 8.0mm2 land area.

°C

S3AB

Unit

S3BB S3DB S3GB S3JB

S3KB S3MB

°C/W

Dimensions in inches and (millimeters)

SMB ( DO-214AA )

.030(0.76)

.060(1.52)

.096(2.44)

.084(2.13)

.200(5.08)

.220(5.59)

.008(.203)

.002(.051)

.006(.152)

.012(.305)

.160(4.06)

.185(4.70)

.130(3.30)

.155(3.94)

.083(2.11)

.075(1.91)

Case: JEDEC SMB/DO-214AA molded plastic body

Terminals: Solder plated , solderable per MIL-STD-750,

Method 2026

Polarity: Color band denotes cathode end

Mounting Position: Any

Weight:0.005 ounce, 0.138 grams
