Ordering Information

Specifications

Optional Accessories

Dimensions

Input Signal

VGA Video: R.G.B Analog 0.7v Peak-to-Peak

Video

S-Video

DVI

Touchscreen: USB interface

Audio-in

3 USB (1 slave, 2 host)

I/O Connector

1 x USB for touchscreen control

1 x VGA input

1 x RCA video

1 x S-Video for video

1 x DVI

1 x lock-type DC power input

1 x Audio-in

2 x USB (2 host)

Power Adapter

Lock type external 24V AC/DC medical grade power

adapter

Touchscreen

Thickness

Resistive: 3.2mm

Light Transmission

Resistive: 80%

Power Consumption Resistive: +5V @ 100mA

Touch Life

Resistive: 35million touches

Controller interface

USB connector

Dimensions

438 mm (17.24") (W) x 68.5 mm (2.69") (D)

x 376.4 mm (14.8") (H)

Packing Dimensions

610 mm (24.02") (W) x 260 mm (10.24") (D)

x 590 mm (23.23") (H)

Weight (net/gross)

8.46 kg (18.52 lb)/10.96 kg (24.16 lb)

Environment

Operating temperature: 0° ~ +45°C (32°F ~ 104°F)

Storage temperature: -20°C ~ +60°C (-4°F ~ +140°F)

Relative humidity: 20% ~ 90%, non-condensing

Certification

UL60601-1, EN60601-1, CE, FCC class B

MMT175

17" TFT medical grade monitor with USB 2.0 interface

resistive touchscreen

MMT175-DVDRW

17" TFT medical grade monitor with USB 2.0

resistive touchscreen, Super Multi drive and 1.3 mega pixels

camera

* Specification and certifications are based on options and may vary.

**Super Multi drive includes DVD-R, DVD-RW and DVD-RAM.

E202003330

VM-101 VESA ARM (clamp type)

E202003329

VM-105 VESA ARM (wall mount type)

E228170100

17" stand kit
