Series AMLDL-RZ

Up to 700mA | LED Driver

www.aimtec.com

Tel: +1 514 620 2722

Toll free: + 1 888 9 AIMTEC

(924 6832)

F 051e R12.E

2 of 17

North America only

General Specifications (continued)

Parameters

Conditions

Typical

Maximum

Units

Maximum case temperature

105

Thermal Impedance

Free air convection

+40

Cooling

Free air convection

Humidity

95

% RH

Case material

Non-Conductive Black Plastic (UL94-V0 rated)

Weight

2.6

g

0.80 x 0.40 x 0.27 inches

20.32 x 10.16 x 6.88 mm

MTBF

Maximum Soldering Temperature

1.5mm from case for 10sec.

260

NOTES:

1.Reversed polarity at the input power will damage the driver. The input ground must not be connected to the negative output.

2.Leave the pin VADJ opened if not used , grounding VADJ will shut the driver off, connecting VADJ to +Vin will damage the driver.

Safety Specifications

Parameters

Standards

Designed to meet EN 60960-1

Pin Out Specifications

Pin

Single

1

- V Input

- DC Supply

2

Vadj

PWM/ON/OFF or not used

7

- V Output

LED Cathode connection

8

+ V Output

LED Anode connection

14

+ V Input

+ DC Supply
