RAM-0505S datasheet(2/2 Pages) RECOM

部件名	RAM-0505S

功能描述	25째C, nominal input voltage and rated output current unless otherwise specified

PDF	2 Pages

Scroll/Zoom	100%

制造商	RECOM [Recom International Power]

网页	http://www.recom-international.com

标志

2 / 2 page

www.recom-international.com

REV:0/2013

RAM Series

ECONOLINE

DC/DC-Converter

100

40%

100%

Efficiency / Load

60%

80%

20%

Total Output current (%)

1205

2405

0505

Deviation / Load

-10

40%

100%

60%

80%

20%

-5

Total Output current (%)

0505

1205

2405

RAM-xx05S

Typical Characteristics

+10%

+5%

V Nom.

+5%

10%

50%

100%

Output Load Current (%)

Typical Load Line

Tolerance Envelope

Package Style and Pinning

3rd angle

projection

8.70

10.65

RECOM

RAM-xx05S

9.00

0.50 pin width

28 27

17 16 15

1 2

12 13 14

4.05 max.

1.27x13

18.00

6.70

1.27

Pin Connections

Pin #

Function

+Vin

-Vin

-Vout

+Vout

14~17

27,28

NC = No Connection

Unit:

Tolerance:

± 0.25 mm

Output

Input

470pF/6kVDC

GND

EMC Filtering - Suggestion for EN55022 Class B

Input

Inductance/

Voltage

Capacitance (C1)

10µF

12V

4.7µF

24V

22µF

E-61
