Type N

Type N

Type N Connectors

Description

Named after Paul Neill of Bell Labs after being developed in the 1940’s, the Type N

offered the first true microwave performance. The Type N connector was developed to

satisfy the need for a durable, weatherproof, medium-size RF connector with consistent

performance through 18 GHz.

There are two families of Type N connectors: Standard N (coaxial cable) and Corru-

gated N (helical and annular cable). Their primary applications are the termination of

medium to miniature size coaxial cable, including RG-8, RG-58, RG-141, and RG-225.

Features/Benefits

•Accommodatesawiderangeofmediumtominiature-sizedRGcoaxialcables

in a rugged medium-sized design.

•Meetsmanycustomerapplicationdemandswithplugstylesavailablein

straight and right angle and jack styles available in panel mount, bulkhead

mount, and receptacle.

Applications

•Antennas

•BaseStations

•Broadcast

•Instrumentation

•MicrowaveRadio

•Mil-Aero

•PCS

•Radar

•Radios

•SatelliteCommunications

•SurgeProtection

•WLAN
