Type N

Type N Specifications

Electrical

Impedance

50 Ω

Frequency range

DC - 11 GHz (flexible cable)

DC - 18 GHz (semi-rigid)

VSWR

1.3 max. @ DC - 11 GHz (straight)

1.35 max. @ DC - 11 GHz (right-angle)

RF-leakage

90 dB minimum @ 3 GHz

Voltage rating (at sea level)

≤ 1,500 V peak (depending on cable)

Contact resistance

center contact: ≤ 1 mΩ

outer contact: ≤ 0.2 mΩ

Insulation resistance

5,000 MΩ minimum

Insertion loss maximum

≤ 0.15 dB @ 10 GHz

Dielectric withstanding voltage

2,500 Vrms (at sea level)

Mechanical

Mating

5/8-24 Threaded coupling (MIL-STD-348)

Coupling torque, min./max.

15 inch lbs to max recommended

Coupling nut retention force

101.2 lbs (450N) min.

Assembly torque (body/clamp nut)

positive stop, 18/20 lb-ft (25/30 N-m)

Braid/Jacket cable affixment

All braid hex crimps, clamps: screw-thread and braid clamp

Center conductor cable affixment

Solder

Captivated contacts

All crimp, unless noted otherwise

Contact Captivation

6.3 lbs (28N) min.

Durability (matings)

500 cycles minimum

Environmental

Temperature range

-65°C to +165°C

- copolymer of styrene:

-55°C to +85°C

Weatherproof

All series N with gaskets

Hermetic seals

Helium leak test, 2 x 10^8 cc/sec.

Thermal shock

MIL-STD-202, method 107, cond. B

Moisture resistance

MIL-STD-202, method 106

Corrosion

MIL-STD-202, method 101, cond. B

Vibration

MIL-STD-202, method 204, cond. B

Mechanical shock

MIL-STD-202, method 213, cond. 1

Type N

Note: These characteristics are typical but may not apply to all connectors.
