CC1150
SWRS037A
Page 6 of 60
4
Electrical Specifications
4.1
Current Consumption
Tc = 25
°C, VDD = 3.0 V if nothing else stated. All measurement results are obtained using the CC1150EM reference
design ([1] and [2]).
Parameter
Min
Typ
Max
Unit
Condition
200
nA
Voltage regulator to digital part off, register values lost (SLEEP
state)
222
µA
Voltage regulator to digital part on, all other modules in power
down (XOFF state)
1.1
mA
Only voltage regulator to digital part and crystal oscillator running
(IDLE state)
Current consumption
7.7
mA
Only the frequency synthesizer running (FSTXON state). This
current consumptions also representative for the other
intermediate states when going from IDLE until reaching TX, and
frequency calibration states
Current consumption,
315 MHz
25.6
14.1
mA
Transmit mode, +10 dBm output power (0xC4)
Transmit mode, 0 dBm output power (0x60)
See more in section 21 and DN012 [3]
Current consumption,
433 MHz
26.1
14.6
mA
Transmit mode, +10 dBm output power (0xC2)
Transmit mode, 0 dBm output power (0x60)
See more in section 21 and DN012 [3]
Current consumption,
868 MHz
29.3
15.5
mA
Transmit mode, +10 dBm output power (0xC3)
Transmit mode, 0 dBm output power (0x60)
See more in section 21 and DN012 [3]
Current consumption,
915 MHz
29.3
15.2
mA
Transmit mode, +10 dBm output power (0xC0)
Transmit mode, 0 dBm output power (0x50)
See more in section 21 and DN012 [3]
Table 4: Electrical Specifications
