Features

insulating material meets UL 94V-0

requirements

Applications

Almost anywhere there is a low voltage power

supply and a load to be protected, including:

MF-R Series - PTC Resettable Fuses

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.

Environmental Characteristics

Operating/Storage Temperature ...................... -40 °C to +85 °C

Maximum Device Surface Temperature

in Tripped State............................................ 125 °C

Passive Aging .................................................. +85 °C, 1000 hours...........................................±5 % typical resistance change

Humidity Aging................................................. +85 °C, 85 % R.H. 1000 hours .........................±5 % typical resistance change

Thermal Shock ................................................ -40 °C to +85 °C, 10 times................................±10 % typical resistance change

Solvent Resistance.......................................... MIL-STD-202, Method 215 ...............................No change

Vibration .......................................................... MIL-STD-883C, Method 2007.1,.......................No change

Condition A

Test Procedures And Requirements For Model MF-R Series

Test

Test Conditions

Accept/Reject Criteria

Visual/Mech. .................................................... Verify dimensions and materials .......................Per MF physical description

Resistance....................................................... In still air @ 23 °C.............................................Rmin

≤ R ≤ Rmax

Time to Trip...................................................... 5 times Ihold, Vmax, 23 °C ...............................T

≤ max. time to trip (seconds)

Hold Current .................................................... 30 min. at Ihold .................................................No trip

Trip Cycle Life.................................................. Vmax, Imax, 100 cycles....................................No arcing or burning

Trip Endurance ................................................ Vmax, 48 hours.................................................No arcing or burning

UL File Number ............................................... E 174545

CSA File Number............................................. CA 110338

TÜV File Number............................................. R2057213

Electrical Characteristics

Model

V max.

Volts

I max.

Amps

Ihold

Itrip

Initial

Resistance

1 Hour (R1)

Post-Trip

Resistance

Max. Time

to Trip

Tripped

Power

Dissipation

Amperes

at 23 °C

Ohms

at 23 °C

Ohms

at 23 °C

Amperes

at 23 °C

Seconds

at 23 °C

Watts

at 23 °C

Hold

Trip

Min.

Max.

Max.

Typ.

MF-R005**

60

40

0.05

0.10

7.3

11.1

22.0

0.5

5.0

0.22

MF-R010

60

40

0.10

0.20

2.50

4.50

7.50

0.5

4.0

0.38

MF-R017

60

40

0.17

0.34

2.00

3.20

8.00

0.85

3.0

0.48

MF-R020

60

40

0.20

0.40

1.50

2.84

4.40

1.0

2.2

0.40

MF-R025

60

40

0.25

0.50

1.00

1.95

3.00

1.25

2.5

0.45

MF-R030

60

40

0.30

0.60

0.76

1.36

2.10

1.5

3.0

0.50

MF-R040

60

40

0.40

0.80

0.52

0.86

1.29

2.0

3.8

0.55

MF-R050

60

40

0.50

1.00

0.41

0.77

1.17

2.5

4.0

0.75

MF-R065

60

40

0.65

1.30

0.27

0.48

0.72

3.25

5.3

0.90

MF-R075

60

40

0.75

1.50

0.18

0.40

0.60

3.75

6.3

0.90

MF-R090

60

40

0.90

1.80

0.14

0.31

0.47

4.5

7.2

1.00

MF-R090-0-9

30

40

0.90

1.80

0.07

0.12

0.22

4.5

5.9

0.60

MF-R110

30

40

1.10

2.20

0.10

0.18

0.27

5.5

6.6

0.70

MF-R135

30

40

1.35

2.70

0.065

0.115

0.17

6.75

7.3

0.80

MF-R160

30

40

1.60

3.20

0.055

0.105

0.15

8.0

8.0

0.90

MF-R185

30

40

1.85

3.70

0.040

0.07

0.11

9.25

8.7

1.00

MF-R250

30

40

2.50

5.00

0.025

0.048

0.07

12.5

10.3

1.20

MF-R250-0-10

30

40

2.50

5.00

0.025

0.048

0.07

12.5

10.3

1.20

MF-R300

30

40

3.00

6.00

0.020

0.05

0.08

15.0

10.8

2.00

MF-R400

30

40

4.00

8.00

0.010

0.03

0.05

20.0

12.7

2.50

MF-R500

30

40

5.00

10.00

0.010

0.03

0.05

25.0

14.5

3.00

MF-R600

30

40

6.00

12.00

0.005

0.02

0.04

30.0

16.0

3.50

MF-R700

30

40

7.00

14.00

0.005

0.02

0.03

35.0

17.5

3.80

MF-R800

30

40

8.00

16.00

0.005

0.02

0.03

40.0

18.8

4.00

MF-R900

30

40

9.00

18.00

0.005

0.01

0.02

45.0

***20.0

4.20

MF-R1100

16

100

11.00

22.00

0.003

0.01

0.014

40.0

20.0

4.50

R

0180T

1

1 0

**CSA approval pending.

***Tested at 40 amps
