Pocket Imager

Advantages

and lighting applications have multiple

benefits for design flexibility.

• High luminance due to pure surface

emission

• High brightness in the white point

thanks to latest multi-chip technology

SMT with only 5.8 x 4.7 x 1.5 mm

Compact with only 3.5 x 3,75 x 1.2

mm

• Very low thermal resistance (Rth)

• Fast switching times

• Dimmable

• Instant on/off function available

• Adjustable color temperature

• Large color range (>105 % NTSC)

• Small form factor

Features

for projection applications are a

compact high-performance light

source, which meet even the most

sophisticated requirements.

architecture

• Long lifetime

• Special optics can be adapted

• Mercury-free, meets the latest

environmental regulations

Applications

The small and robust OSRAM

parts and deliver a wide color range.

They enable manufacturers to

produce:

• Pico projectors (as mobile phone

accessories or embedded devices)

• Pocket projectors

• Projection TVs

• Front projectors for home cinemas

• General lighting applications

• Color changing wallwashers

• RGB floodlights

• Effect lighting

New possibilities

These new innovative products open

the door for new application possi-

bilities. Contact your OSRAM Opto

Semiconductors application specialist

to assist with your specific design.

Internet:

www.osram-os.com/ostar-projection

For further information on the

available products please visit our

product catalog at

http://catalog.osram-os.com

Type

Chip size

max lp

Wavelength

LE x* Q9WM

0,560 µm²

1,5A

617 nm

LE x* Q9WN

1,0 µm²

2,0A

525 nm

LE x* Q9WP

2,0 µm²

6,0A

465 nm

Type

Color

Wavelength

LE A S2W

red

617 nm

LE T S2W

green

529 nm

LE B S2W

blue

464 nm

LE UW S2W

ultra white

5000 K-8000 K**

LE ATB S2W

red, green, blue

617 nm, 529 nm, 464 nm

** Color temperature
