TYP.

3.0

(.118)

TYP.

MAX.

2.8

(.110)

10.0 ± 0.2

(.393 ± .008)

12.7 ± 0.2

(.500 ± .008)

5.0 ± 0.3

(.197 ± .012)

7.6 ± 0.3

(.299 ± .012)

2.4 ± 0.2

(.094 ± .008)

TYP.

2.5 ± 0.2

(.098 ± .008)

7.3

(.287)

Features

Applications

- Portable communications equipment

- Camcorders

- LCD TVs

- Car radios

SDR1005 Series - SMD Power Inductors

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

Test Voltage .................... 0.1 V, 100 KHz

Reflow Soldering .. 250 °C, 10 sec. max.

(in compliance with JEDEC,

J-STD-020C, Table 4-2)

Operating Temperature

................................-40 °C to +125 °C

(Temperature rise included)

Storage Temperature

................................-40 °C to +125 °C

Resistance to Soldering Heat

........................ +250 °C, 10 sec. max.

Electrical Specifications

Bourns

Part Number

Inductance

1 kHz

Q

Ref.

Test

Frequency

Q (MHz)

SRF

Min.

(MHz)

RDC

Max.

(

Ω)

I rms

Max.

(A)

I sat

Typ.

(A)

(µH)

Tol. %

SDR1005-R68ML

0.68

± 20

26

7.960

160

0.006

8.50

9.50

SDR1005-1R0ML

1

± 20

55

2.600

137

0.007

7.50

9.00

SDR1005-1R5ML

1.5

± 20

50

3.000

95

0.009

6.50

8.00

SDR1005-2R2ML

2.2

± 20

51

2.470

65

0.012

6.10

7.00

SDR1005-2R5ML

2.5

± 20

49

3.000

56

0.012

5.50

7.00

SDR1005-3R3ML

3.3

± 20

45

2.520

54

0.015

5.00

6.40

SDR1005-4R7ML

4.7

± 20

46

2.700

42

0.019

4.50

5.40

SDR1005-6R8ML

6.8

± 20

56

2.000

31

0.030

3.40

4.50

SDR1005-100ML

10

± 20

43

4.000

26

0.050

2.90

3.70

SDR1005-150ML

15

± 20

42

2.700

22

0.060

2.50

3.00

SDR1005-220ML

22

± 20

29

2.520

18

0.10

2.00

2.50

SDR1005-330KL

33

± 10

29

2.200

14

0.12

1.80

2.00

SDR1005-470KL

47

± 10

30

2.200

12

0.19

1.40

1.60

SDR1005-680KL

68

± 10

24

2.200

11

0.24

1.20

1.40

SDR1005-101KL

100

± 10

41

0.056

8

0.33

1.00

1.20

SDR1005-151KL

150

± 10

58

0.087

6

0.59

0.80

1.00

SDR1005-221KL

220

± 10

50

0.068

5

0.78

0.70

0.80

SDR1005-331KL

330

± 10

56

0.070

4

1.15

0.55

0.60

SDR1005-471KL

470

± 10

60

0.081

4

1.70

0.45

0.50

SDR1005-681KL

680

± 10

72

0.096

3

2.60

0.35

0.40

SDR1005-102KL

1000

± 10

78

0.122

2

3.90

0.30

0.35

SDR1005-152KL

1500

± 10

97

0.131

2

6.30

0.25

0.30

SDR1005-222KL

2200

± 10

85

0.128

2

8.20

0.20

0.24

SDR1005-332KL

3300

± 10

106

0.128

1

14.00

0.16

0.18

SDR1005-472KL

4700

± 10

96

0.125

1

17.00

0.15

0.16

SDR1005-682KL

6800

± 10

105

0.171

1

30.00

0.11

0.12

SDR1005-822KL

8200

± 10

102

0.145

1

34.00

0.11

0.12

SDR1005-103KL

10000

± 10

102

0.138

1

39.00

0.10

0.11

General Specifications

Core....................................... Ferrite DR

Wire ............................Enameled copper

Base ................................................DAP

Terminal ........................................ Cu/Sn

Rated Current

................... Ind. drop 10 % typ. at Isat

Temperature Rise

....................15 °C max. at rated I rms

Packaging.................... 600 pcs. per reel

Materials

Product Dimensions

Recommended Layout

Electrical Schematic

DIMENSIONS:

MM

(INCHES)
