ADA4075-2ACPZ-R7 数据表(PDF) 13 Page - Analog Devices

部件名 ADA4075-2ACPZ-R7
功能描述  Ultralow Noise Amplifier at Lower Power
PDF  24 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
制造商  AD [Analog Devices]
网页  http://www.analog.com
标志 AD - Analog Devices

ADA4075-2ACPZ-R7 数据表(HTML) 13 Page - Analog Devices

Back Button ADA4075-2ACPZ-R7 Datasheet HTML 9Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 10Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 11Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 12Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 13Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 14Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 15Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 16Page - Analog Devices ADA4075-2ACPZ-R7 Datasheet HTML 17Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 13 / 24 page
background image
Data Sheet
ADA4075-2
Rev. B | Page 13 of 24
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±15V
Figure 45. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0Ω
VSY = ±15V
RS1
RS2
Figure 46. Current Noise Density
TIME (1s/DIV)
VSY = ±15V
Figure 47. 0.1 Hz to 10 Hz Noise
1
10
1
10
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±5V
Figure 48. Voltage Noise Density
1
10
100
1k
10k
100k
FREQUENCY (Hz)
0.1
1
10
CORRELATED
RS1 = RS2
UNCORRELATED
RS1 = 0Ω
VSY = ±5V
RS1
RS2
Figure 49. Current Noise Density
TIME (1s/DIV)
VSY = ±5V
Figure 50. 0.1 Hz to 10 Hz Noise
