Cable connectors – quick guide and selection table

Size

Shape

Type

Features

Material

Order code

Extended

Portfolio

andSpecs

on Page

Nut

Cable

General

purpose

(screw)

3 pin (LED

optionally)

Brass (CuZn)

PVC 2 m

PUR 2 m

XS3F-M8PVC3S2M

XS3F-M8PUR3S2M

XS3F-M8PVC3A2M

XS3F-M8PUR3A2M

4pin

PVC 2 m

PUR 2 m

XS3F-M8PVC4S2M

XS3F-M8PUR4S2M

XS3F-M8PVC4A2M

XS3F-M8PUR4A2M

Detergent

resistant

4 pin

Stainless

steel

(SUS316L)

PVC 2 m

Y92E-

S08PVC4S2M-L

Y92E-

S08PVC4A2M-L

Robotic

4 pin

Brass (CuZn)

Robotic

PVC 2 m

XS3F-M421-402-R

XS3F-M422-402-R

M12

General

purpose

(screw)

3 wire (LED

optionally)

Brass (CuZn)

PVC 2 m

PUR 2 m

XS2F-M12PVC3S2M

XS2F-M12PUR3S2M

XS2F-M12PVC3A2M

XS2F-M12PUR3A2M

4 wire

PVC 2 m

PUR 2 m

XS2F-M12PVC4S2M

XS2F-M12PUR4S2M

XS2F-M12PVC4A2M

XS2F-M12PUR4A2M

5 wire

PVC 2 m

PUR 2 m

XS2F-M12PVC5S2M

XS2F-M12PUR5S2M

XS2F-M12PVC5A2M

XS2F-M12PUR5A2M

Detergent

resistant

4 wire

Stainless

steel

(SUS316L)

PVC 2 m

Y92E-

S12PVC4S2M-L

Y92E-

S12PVC4A2M-L

105°C

Heat

resistant

4 wire

Stainless

steel

(SUS316L)

Heat resist-

ant PVC

XS2F-E421-D80-E

XS2F-E422-D80-E

Twist & click 4 wire

Nickel plated

Zinc

PVC 2 m

PUR 2 m

XS5F-D421-D80-A

XS5F-D421-D80-P

XS5F-D422-D80-A

XS5F-D422-D80-P

Robotic

4 wire

Brass (CuZn)

Robotic

PVC 2 m

XS2F-D421-D80-R

XS2F-D422-D80-R

Fiber

amplifi-

er (E3X)

connec-

tor

Fiber

amplifier

connectors

Special

fiber

connector -

4 wire

PBT

PVC 2 m

E3X-CN21

Special

fiber

connector +

M8 plug

Plug: Zinc

diecast

PVC 30 cm

with M8

4-pin plug

E3X-CN21-M3J-2 0.3M

Special

fiber

connector +

M12 plug

PVC 30 cm

with M12

4-pin plug

E3X-CN21-M1J 0.3M

Photo-

micro-

sensor

(EE-SX)

connec-

tor Cable

connec-

tor

Cable

connector

standard

cable

Nylon

PVC 1 m

EE-1017 1M

robotic

cable

EE-1017-R 1M

M8/M12

Confection-

able

Plugs and

connectors

for self

assembly

Brass

n.a.

XS2G, XS2C

Y92E_conf

M12

Field I/0

boxes

Direct

wiring or

DeviceNet

communi-

cation

XW3B, DRT2

M8/M12

T-connectors,

covers,

accessories

and extended

wiring

portfolio

n.a.

XS2R, XS3R, XY2F, ..
