Molding Type Power Inductor

|| | | | | | | | | | | | | |

ASPI-0630LR

Compliant

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

ABRACON IS

ISO 9001:2008

CERTIFIED

7.2 x 6.65 x 3.0 mm

30332 Esperanza, Rancho Santa Margarita, California 92688

Revised: 11.17.11

Visit www.abracon.com for Terms & Conditions of Sale

RVES

PART NUMBER IDENTIFICATION

OUTLINE DRAWING:

Dimension: mm

Recommended Land Pattern

A

A'

B

B'

L

W

H max

1.6 ±0.4

2.0 ±0.1

3.0 ±0.3

3.4 ±0.2

7.2 ±0.3

6.65 ±0.2

3.0

A

B

C

8.4

3.7

3.4

ASPI-0630LR-

-

Inductance Code

Please refer to the

Electrical Spec Table

Packaging

T15: Tape and Reel (1.5kpcs /

reel)

Tolerance

M: ±20%
