Mechanical Diagrams

CMS1 Series

Part Number

OCL

I rms.

DCR (

Ω) typ

DCR (

Ω) typ

Leakage

Interwinding

(uH) minimum

Amperes

@ 20°C

@ 20°C

Inductance (uH)

Capacitance (pF)

(1-2) & (3-4)

Max *

(1-2)

(4-3)

typ

typ

CMS3-4-R

88

3.95

0.010

0.010

0.85

3.50

CMS3-5-R

146

3.10

0.017

0.017

1.30

3.70

CMS3-6-R

217

2.85

0.020

0.020

1.90

3.90

CMS3-7-R

258

2.45

0.027

0.027

2.20

4.15

CMS3-8-R

350

2.00

0.040

0.040

3.00

4.40

CMS3-9-R

400

1.70

0.053

0.053

3.30

4.65

CMS3-10-R

518

1.45

0.076

0.076

4.20

4.85

CMS3-11-R

648

1.20

0.107

0.107

5.10

5.10

CMS3-12-R

790

1.05

0.145

0.145

6.10

5.35

CMS3-13-R

1030

0.88

0.210

0.210

7.80

5.55

CMS3-14-R

1310

0.75

0.300

0.300

9.60

5.80

Definitions:

OCL = Open Circuit Inductance

DCR = Direct Current Resistance

Irms = rms current for approx. a 40°C temperature rise at an ambient temperature of 85°C.

*Operating Temperature: 160°C Max. Inductance values are sustained up to 160°C.

Electrical Characteristics:

OCL (1-2) 0.10Vrms, 100kHz, 0.0Adc: (See Chart)

OCL (4-3) 0.10Vrms, 100kHz, 0.0Adc: (See Chart)

DCR (1-2) typ @ 20°C: (See Chart)

DCR (4-3) typ @ 20°C: (See Chart)

Hipot rating: winding to winding: 300Vdc min. for 1 second.

Turns Ratio: (1-2):(4-3) 1:1

3

3

3

3

3

4

4

4

4

4

2

2

2

2

2

1

1

1

1

1

TOP VIEW

F

9.4 max

7.2 max

Pin 1 indicator

White dot

2

wwllyy R

CMS1-

FRONT VIEW

R

2.6 max

w

RECOMMENDED PCB LAYOUT

S

SCHEMATIC

4

1

3

1:1

2

CMS2 Series

CMS3 Series

CMS-SERIES

Common Mode Inductors

(Surface Mount)

wwllyy = Date code R = Revision level
