General Purpose Relays

Industrial Relays

08-2011, Rev. 0811

www.te.com

© 2011 Tyco Electronics Corporation,

a TE Connectivity Ltd. company

Datasheets and product specification

according to IEC 61810-1 and to be used

only together with the ‘Definitions’ section.

Datasheets and product data is subject to the

terms of the disclaimer and all chapters of

the ‘Definitions’ section, available at

http://relays.te.com/definitions

Datasheets, product data, ‘Definitions’ sec-

tion, application notes and all specifications

are subject to change.

4

Potter & Brumfield

Terminal type

Solder/plug-in terminals, PCB-THT,

8- or 11-PIN octal type plug

Weight

23 to 40g

Packaging/unit

tray/50 pcs., box/350pcs.

Accessories

For details see datasheet

Sockets and Accessories, R10 Relays

Product Code Description

Many versions of sockets and clips available.

NOTE: Relays with contact current <50mA are not recommended for use in sockets.

Insulation Data

Initial dielectric strength

between open contacts

between contact and coil

between adjacent contacts

Initial insulation resistance

between insulated elements

10GΩ, 500VDC

Other Data

Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content

refer to the Product Compliance Support Center at

www.te.com/customersupport/rohssupportcenter

Ambient temperature

-55ºC to 75ºC

Category of environmental protection

IEC 61810

RTI - dust protected and RTIII - wash tight

Terminal dimensions

Solder terminal dimensions

Printed circuit terminal dimensions

Terminal assignment

R10 - AC Coil Diagram

Dimensions

.735 MAX.

(18.67)

1.187 MAX .

(30.15)

R10S: 1.50 MAX.

(38.1)

.406

(10.31)

.135

(3.43)

.210

(5.33)

3-48THREAD

NIB .091 DIA. x .020 HIGH

(2.31) (.51)

.354

(8.99)

#6-32

THREAD

.375

(9.53)

.171

(4.43)

.156

(3.96)

CASE R ONLY

Recommend tape tab

be removed after

immersion cleaning

and before relay is put

in service. Peel off to

permit proper relay

ventilation.

2 POLE .950 MAX.

(24.13, 2 POLE 1R10)

4 POLE 1.165 MAX.

(29.59, 4 POLE 1R10)

6 POLE 1.375 MAX.

(34.93)

8 POLE 1.580 MAX.

(40.13)

.437

(11.10)

.59 REF.

(15.0)

STUD ON NARR OW

SIDE ONLY

CASE E

ONLY

TYPE E6 ONLY

.085 MAX.

(2.16)

TYPE E6 ONLY

.012

(.30)

.040

(1.02)

.090

(2.29)

.080

(2.03)

D

(TO TOP OF CASE)

B

A

C

A

B

C

D

Arrang.

Type 2

.131

.050

.064

1.251

Inline

Type 7

.131

.040

.013

1.20

Inline

Type 9

.170

.040

.000

1.187

Staggered

Thickness

.012

.012

.012

.013

–––

26

27

14

1 POLE

8

9

5

10

6

7

4 3 2

1

2 POLE

8

9

5

10

6

7

4 3 2

1

3 POLE

4 3 2

1

4 POLE

4 3 2

1

14

15

8

16

9

10

11

12

5

13

6

7

14

15

8

16

9

10

11

12

5

13

6

7

6 POLE

4 3 2

1

19

9

10

20

21

11

14

15

5

17

18

8

8 POLE

4 3 2

1

22

12

13

16

6

7

22

9

10

23

24

11

17

18

5

20

21

8

25

12

13

19

6

7

28

15

16

DUAL

COIL
