ADP1720
Rev. A | Page 9 of 16
–100
10
10M
0
FREQUENCY (Hz)
100
1k
10k
100k
1M
VIN = 8V
VOUT = 5V
COUT = 1µF
VRIPPLE = 50mV
–10
–20
–30
–40
–50
–60
–70
–80
–90
1mA
10mA
100µA
Figure 15. Power Supply Rejection Ratio vs. Frequency
(5.0 V Fixed Output)
TIME (20µs/DIV)
1
VIN = 12V
VOUT = 1.6V
CIN = 1µF
COUT = 1µF
LOAD STEP FROM 2.5mA TO 47.5mA
VOUT
Figure 16. Load Transient Response
TIME (100µs/DIV)
2
1
VOUT = 5V
CIN = 1µF
COUT = 1µF
ILOAD = 50mA
VIN STEP FROM 6V TO 7V
VOUT
Figure 17. Line Transient Response
TIME (40µs/DIV)
2
1
VIN = 12V
VOUT = 5V
CIN = 1µF
COUT = 1µF
ILOAD = 50mA
EN
VOUT
Figure 18. Start-Up Time
