TAPE & REEL SPECIFICATIONS

REEL OUTLINE DIMENSIONS

TAPE OUTLINE DIMENSIONS

1.20

(30.4) Max.

0.94-1.08 (23.9-27.4)

0.53 (13.50)

0.50 (12.80)

0.059 (1.50)

Min.

2.36 (60) Min.

0.80 (20.20) Min.

3.9 (100)

Min.

Leader section

15.7 (400) Min.

Goods

enclosure

section

Trailer section

6.3 (160) Min.

Ø15.039 (382) Max.

Ø

Ø

*

0.96 (24.4)

1.04 (26.4)





Unless otherwise stated all

dimensions in inches (mm) ±0.01(0.25).

* Includes flange distortion at outer edge.



Measured at hub.

0.024 (0.60) Max.

0.283 (7.20)

0.369 (9.37)

Direction of unreeling

0.069 (1.75)

0.157 (4.00)

0.079 (2.00)

0.472 (12.00)

Cover tape

0.059

(1.50

)

+0.004

-0.000

+0.10

-0.00

Unless otherwise stated all

dimensions in inches (mm) ±0.01(0.25).
