h

w

h

f

d

Reel

Upper side

Tape

Lower side

User

direction

of

feed

t

User direction of feed

Cross section A - B

Δp

Δp

H

Reference plane

W

A

B

F

L

Δh

Δh

IEC

EIA

Dimensions

Dimension Description

Mark

Mark

Dimensions

Tolerance

Lead spacing: MF-R, MF-R/90, MF-R/600, MF-RX, MF-RX/72

F

F

5.08

±0.2

(0.2)

(±0.008)

Lead spacing: MF-RX/250

F

F

5.08

-0.5/+0.6

(0.2)

(-.020/+.024)

Reel width

w

W2

56.0

max.

(2.205)

Reel diameter

d

a

370.0

max.

(14.57)

Space between flanges less device

4.75

±3.25

W1

h

(.187)

(±.128)

Arbor hole diameter

f

c

26.0

±12.0

(1.024)

(±.472)

Core diameter: MF-R, MF-RX, MF-R/90

h

n

80

max.

(3.15)

Core diameter: MF-RX/250, MF-R/600

h

n

91

max.

(3.58)

Box: MF-R, MF-RX, MF-R/90

62

355

345

nom.

(2.44) (14.0)

(13.6)

Box: MF-RX/250

67

372

362

max.

(2.64) (14.6) (14.25)

Box: MF-R/600

64

372

362

max.

(2.52) (14.6) (14.25)

Consecutive missing places: MF-R, MF-RX, MF-R/90

3

max.

Consecutive missing places: MF-RX/250, MF-R/600

none

Empty places per reel: MF-R, MF-RX, MF-R/90

Not specified

Empty places per reel: MF-RX/250, MF-R/600

0.1 %

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.

Taped Component Dimensions -

Figure 1

DIMENSIONS:

MM

(INCHES)

MF-R, MF-R/90, MF-R/600, MF-RX, MF-RX/72 & MF-RX/250 Series

Tape and Reel Specifications

Reel Dimensions - Figure 2
