1. Introduction

The EMPCB.SMAFSTJ.B.HT connector was designed to be mounted on a PCB edge. The edge

mount configuration allows the connector to be easily slotted onto a PCB board; the maximum

thickness of PCB that the connector can be used with is 0.8mm. The connector pin is directly

soldered onto pads on the PCB. The connector is a standard SMA (F) Jack. The SMA connector is

the most popular type connector for RF applications. Taoglas connectors are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

0~12.4 GHz

Working Voltage

Max. 335 Vrms

Insulation Resistance

Min. 5000M ohms

MECHANICAL

Connector Dimension

6.35 X 6.35 X13.3 mm

Max. Thickness PCB acceptable

0.8 mm

Connector Pin Diameter

0.76 mm

Connector Type

SMA (F) to PCB Edge Mounted

ENVIRONMENTAL

RoHS compliant
