Legend

+25 ºC

+85 ºC - - - - - - -55 ºC

Typical Intermodulation Performance at 25 ºC

Second Order Harmonic Intercept Point ....... +52 dBm (Typ.)

Second Order Two Tone Intercept Point ........ +46 dBm (Typ.)

Third Order Two Tone Intercept Point ............ +37 dBm (Typ.)

Power

Vdc

+15

+15

m A

150

160 Max.

RF AMPLIFIER

MODEL

TM3002

Available as:

TM3002, 4 Pin TO-8 (T4)

TN3002, 4 Pin Surface Mount (SM3)

FP3002, 4 Pin Flatpack (FP4)

BX3002, Connectorized Housing (H1)

Features

!

!

!

!

! High Output Power: +26 dBm Typical

!

!

!

!

! High Third Order Intercept: +37 dBm Typical

!

!

!

!

! Operating Temp. -55 ºC to + 85 ºC

!

!

!

!

! Environmental Screening Available

CHARACTERISTIC

TYPICAL

MIN/MAX

Ta= 25 ºC

Ta = -55 ºC to +85 ºC

Frequency

1400 - 2400 MHz

1400 - 2400 MHz

Note: Care should always be taken to effectively ground the case of each unit.

Noise Figure (dB)

<4.0

6.0 Max.

VSWR

In

<2.25:1

2.75:1 Max.

Out

<1.50:1

2.0:1 Max.

Reverse

Isolation (dB)

-18

-16 Max.

Power @ 1 dB

Comp. (dBm)

+26

+25 Min.

Gain (dB)

12

10.5 Min.

Specifications

Typical Performance Data

Absolute Maximum (No Damage) Ratings

Ambient Operating Temperature ................ -55ºC to +100 ºC

Storage Temperature ................................. -62ºC to +125 ºC

Case Temperature .................................................. +125 ºC

DC Voltage .......................................................... +18 Volts

Continuous RF Input Power .................................. +18 dBm

Short Term RF Input Power ...... 50 Milliwatts (1 Minute Max.)

Maximum Peak Power .................... 0.5 Watt (3

µsec Max.)

Rev.

9/10/09

3.0

2.0

1.0

2.0

1.5

1.0

2

6

4

14

12

10

29

28

27

26

25

0

- 10

- 20

- 30

- 40

Stop 2400 MHz

Stop 2400 MHz

Stop 2400 MHz

Stop 2400 MHz

Stop 2400 MHz

Stop 2400 MHz

11

13

3

5

Start 1400 MHz

Start 1400 MHz

Start 1400 MHz

Start 1400 MHz

Start 1400 MHz

Start 1400 MHz

Gain (dB)

Noise Figure (dB)

1 dB Comp. (dBm)

Input VSWR

Output VSWR

Reverse Isolation (dB)

======================================================================================

1400

1500

1600

1700

1800

1900

2000

2100

2200

2300

2400

.27

.26

.24

.22

.18

.14

.10

.06

.10

.19

.29

179

174

168

162

154

146

132

82

-4

-36

-56

3.96

4.03

4.05

4.14

4.18

4.27

4.28

4.17

4.12

4.11

3.98

82

73

64

54

45

34

22

10

0

-13

-26

.11

.10

.11

.11

.10

.11

.11

.10

.10

.10

.10

-44

-47

-51

-55

-56

-62

-68

-73

-78

-84

-87

.16

.15

.13

.13

.12

.12

.13

.14

.13

.12

.12

45

31

15

-8

-31

-50

-79

-106

-128

-143

-144

Linear S-Parameters

MHz

Freq.

Mag Deg

Mag Deg

Mag Deg

Mag Deg

----S11----

----S21----

----S12----

----S22----
