SPECIFICATION CONTROL DRAWING

TE Connectivity

300 Constitutional Drive

Menlo Park, CA 94025 USA

RAYCHEM

TITLE:

SOLDERSLEEVE* SHIELD TERMINATOR,

IMMERSION RESISTANT, MIL-S-83519/2

UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS.

INCHES DIMENSIONS ARE BETWEEN BRACKETS.

DOCUMENT NO:

S02-XX-R

TOLERANCES:

0.00 N/A

0.0 N/A

0 N/A

ANGLES:

N/A

ROUGHNESS

IN MICRON

TE Connectivity reserves the right to

amend this drawing at any time. Users

should evaluate the suitability of the

product for their application.

DATE:

16-Apr-11

DOC ISSUE:

4

DRAWN BY:

M. FORONDA

CAGE CODE:

06090

REPLACES:

D970095

DCR NUMBER:

D981342

PROD. REV.:

SEE TABLE

SCALE:

None

SIZE:

A

SHEET:

1 of 1

Product Name

Product Dimensions

Cable Dimensions

Product Rev.

Product Rev.

Product Rev.

Product Rev.

A1.75

øB

øC

H

øE

øF

øG

øD

J0.5

20 AWG

22 AWG

24 AWG

26 AWG

(A0.07)

min

min

min

max

min

min

max

(J0.02)

S02-01-R

D

S02-06-R

D

S02-11-R

D

S02-16-R

D

16.5

(0.650)

1.90

(0.075)

2.65

(0.105)

8.25

(0.325)

2.65

(0.105)

0.90

(0.035)

0.50

(0.020)

1.90

(0.075)

7.5

(0.295)

S02-02-R

D

S02-07-R

D

S02-12-R

D

S02-17-R

D

16.5

(0.650)

2.65

(0.105)

3.68

(0.145)

8.25

(0.325)

3.68

(0.145)

1.40

(0.055)

0.75

(0.030)

2.65

(0.105)

7.5

(0.295)

S02-03-R

D

S02-08-R

D

S02-13-R

D

S02-18-R

D

16.5

(0.650)

4.30

(0.170)

5.08

(0.200)

8.25

(0.325)

5.08

(0.200)

2.15

(0.085)

1.25

(0.050)

4.30

(0.170)

7.5

(0.295)

S02-04-R

D

S02-09-R

D

S02-14-R

D

S02-19-R

D

19.1

(0.750)

5.95

(0.235)

6.45

(0.255)

8.25

(0.325)

6.45

(0.255)

3.30

(0.130)

1.80

(0.070)

5.95

(0.235)

7.5

(0.295)

S02-05-R

D

S02-10-R

D

S02-15-R

D

S02-20-R

D

19.1

(0.750)

7.00

(0.275)

7.60

(0.300)

8.25

(0.325)

7.60

(0.300)

4.30

(0.170)

2.50

(0.100)

7.00

(0.275)

7.5

(0.295)

MATERIALS

1. INSULATION SLEEVE: Heat-shrinkable, transparent blue, radiation cross-linked polyvinylidene fluoride.

2. SOLDER PREFORM WITH FLUX AND THERMAL INDICATOR:

SOLDER:

TYPE Sn63 per ANSI-J-STD-006.

FLUX:

TYPE ROL1 per ANSI-J-STD-004.

THERMAL INDICATOR: Color change: violet to colorless.

3. MELTABLE RING: Environment resistant thermoplastic. Color:blue.

4. GROUND LEAD: MIL-W-22759/32-AA-90 lead gauge per table.

APPLICATION

1. These parts are designed to provide an environment resistant shield termination on cables meeting the following criteria:

Dimensions: Per table.

Jacket rating: 125C.

Shield plating: Tin or silver.

Jacket material: See M83519/2 or consult Raychem.

2. Parts are qualified to M83519/2.

3. For assembly information, refer to Raychem document RCPS-100-70.

For best results, prepare

the cable as shown:

* A trademark of TE Connectivity.
